PACKAGE CONTENT
1 x M88 DSP / M88 DSP Dante
1 x User’s manual
SPECIFICATIONS
Example version 16x16 M88 DSP Dante
- Processor: ADI SHARC 21489(x2)
- Sampling Rate: 48Khz/24 bits
- Input gain: 0 to 48dBu
- Phantom Power: 48V
- Frequency response (20~20KHz): ±0.2dB
- Maximum level: +18dBu
- THD: 0.001%@4dBu
- Dynamic range: 110 dB
- Background noise (A-weighted): -91 dB
- Separation between channels at 1 KHz: 108 dB
- Input impedance (balanced connection): 9.4 KΩ
- Audio format: 24 bit MSB TDM
- Delay: <3ms
- Operating power: AC 110~240V 5Hz-60Hz.
- Maximum power consumption <40W
- Dimensions (Width x Depth x Height): 482 x 260 x 45 mm
- Weight: 3KG
OVERVIEW
Introduction
The M88 series is equipped with several basic technical features to make the work of
audio engineers easier. Audio hardware is controlled and programmed through NexusX
3.0 software, (Windows). This Manual mainly presents the techniques used to achieve the
objective.
NexusX is a Windows-based application used to perform configuration and control of DSP
hardware. The DSP controller has 16 built-in presets and the modules and sequences for
each preset can be flexibly designed according to the designer's requirements. Once the
design is complete, it can be saved for future use. The sequences and parameters of the
DSP controller's integrated processing modules adapt to most application scenarios
without any changes.
NexusX is a full-featured application that includes parameter adjustment and peripheral
accessory configuration of all modules, such as RS232, RS485, click-and-drag panel
configuration and Dante network audio control, etc. The most interesting part is the user
interface, which allows you to customize the user interface to operate the unit in a simple
environment adjusted to the needs of each installation. Advanced control functions allow
the user to access the unit's full settings.
M88 DSP / M88 DSP Dante
www.audibax.com 3
