Velocity
13
System Settings
Set the time, time zone, and date for Velocity.
Select this button to allow Velocity to sync its clock with the
server.
Time Settings
API Settings
Enable NTP Clock Synchronization
NOTE: The gateway must be online in order for the
clock to synchronize with the server.
API is used for integrating Velocity with a pre existing
control system. Select the enabled slider and type in the
port to activate API integration.
NOTE: Once changes have been made, restart
Velocity using the Restart Velocity button in the
Tools tab.
• Select the + button to link to any other Velocity
Gateways on the network. A pop up will appear.
• Enter the IP address of the other gateway.
• Press the OK button.
• Press the Synchronize Gateways. A pop up will
appear when complete.
• Enable this feature to set up notications
when issues arise.
• Once enabled, press the + sign. A pop
up will appear that the name for the
notication device can be entered into.
• Press OK once the name is entered.
• Enter the IP Address in the IP Address
eld.
• The next eld is for the IP Port.
• The nal eld is for the community string,
which is dened by the watch device.
Enable this to have Velocity update a device IP address if it
changes to the new address and has the MDNS hostname
or MAC address associated to it within the software. e.g.
If a device is set to DHCP and the IP is renewed to a new
address, it will auto update in Velocity.
Linked Gateways
SNMP
Atlona Device Manager Settings
