Velocity
98
Macros & Conditions
• Command - Select the command from the drop down list available for the room/device. Device
commands are based o the device driver within Velocity.
NOTE: Velocity has built in commands that can be used for control and each command will have extra
parameters that will appear below the command once selected.
◊ Conferencing - Dialer Button - For use with Biamp Tesira driver.
◊ Conferencing - Dialer Call - For use with Biamp Tesira driver.
◊ Devices - Reconnect Device - This will refresh the connection of
the selected device.
◊ Devices - Send Command - This will send a command of the
current value of the set variable to the chosen device. This will be
used with the Custom Control Interface buttons.
◊ Devices - Show Hide Displays - This macro will provide a way to
show and hide room displays.
◊ Custom GUI - Button Click - This macro will allow dened
buttons to display after it is used.
◊ Miscellaneous - Restart Velocity - This will restart Velocity when
the macro is triggered. Allow up to ve minutes for Velocity to
restart.
◊ Miscellaneous - Send Email - Sets up so an email can be sent
to a specic address with a specic subject and body when
triggered. Velocity must have internet access for this function to
work.
◊ Miscellaneous - Wake On LAN - Velocity will trigger the device
at the specied MAC address using the Wake On LAN “magic
packets”.
◊ Room - Close Room - Used with divisible rooms to split the
current room into two independent rooms.
◊ Room - Open Room - Used with divisible rooms to take the
currently split room and merge them into one room.
◊ Room - Room ON - Triggered, this will send all the room on
commands to the selected room and set any control screen or
touch-pad to the home page.
◊ Room - Room OFF - This will send all room o commands and
set the control screens or touch-pads to the home page when
triggered.
◊ Web - HTTP cURL Request - Triggers the cURL command
entered into parameters.
◊ Web - HTTP cURL (ARGS) Request - Triggers the cURL
command entered into parameters with variables.
