Velocity

59

1. Select a command or macro from the drop down menu. If editing a current button, the command will

already be selected.

2. Select between ASCII and HEX for the Command Encoding type.

3. *Optional* If the command needs repeating (such as volume up), type the time in milliseconds in the the

Repeat Interval eld.

4. *Optional* Select the ON RELEASE tab for commands that require a follow up command. e.g. Pan

tilt stop for any on press commands for pan tilt. The selected command will send once the button is

released.

5. Select the BUTTON STYLE tab to provide a custom look for the button.

6. Select the Icon and Button Visible Features. Once customization options are chosen, the button will

preview to the right, if Visible is selected.

7. *Optional* Select the custom image slider to import a custom button background. Drag and drop the

image into the upload or drag box or press the upload or drag button to browse the local computer for

the custom button background.

Control

b. Select Add to create new buttons that are not part of the original remote. A new pop up window will appear.

NOTE: This is the same screen that will be

seen for editing a current button. To edit a

button already on the remote, double click the

button to open the Button Builder window.
