Velocity

33

Home Page

Gateway Information

Usage Information

The Gateway Information eld will display rooms, devices, gateways, and sites. This will update whenever a new site

or device is added. If the numbers do not update, refresh the browser screen.

Usage tiles will appear at the bottom of the home page. This will display status of the Velocity gateway.

Up time will display how long the software has been online at the current site.

It will display in weeks, days, hours, and minutes.

Memory, CPU, and Disk Usage tiles will display the status of the server. This will display the percentage of use on the

VGW-HW or the percentage of allocated resources in use on the server for VGW-SW.

• Green (0 - 74.9%) - Optimal

• Yellow (75 - 89.9%) - Getting close to maximum system ability

• Red (90% and above) - System is being overtaxed. System may need upgrading if deleting extra macros,

variables, and images does not bring system back down to at least yellow.

Select any of the options (except for Total Devices) to go to the relevant section within the software. e.g. If Linked

Gateways is selected, it will open the Gateway tab within the Settings page.

Total Rooms - Displays the total amount of rooms on the gateway and linked gateways.

Available Room Licenses - Displays the total amount of licenses left. This can be negative if more rooms are

created than there are licenses.

Total Devices - Displays the total of all devices on the gateways (Atlona devices, displays, sources, etc)

Devices are Online - Displays the number of Atlona devices that are connected and communicating with Velocity.

Devices Disconnected - Displays the number of Atlona devices that are have been added but are not

communicating with Velocity.

Linked Gateways - Shows the number of gateways on the network that have been linked together.

Sites - Displays the number of sites on all connected gateways.
