Velocity
157
Custom Control Interface
Append Variable
Append variable provides a way to edit a variable within the control screen. This can be used for editing text or
numerical variables for dial pads, password pads, and more.
The following example will provide instructions on how to create a custom dial pad.
• Create the buttons for the dial pad and the KeyPadDisplay (variable) button.
• Double click each button and set up the On Press command.
• The Device will need to be set to Variable Actions, Command to Append Variable, Device to System, and
Variable to whatever the dial variable will be (e.g. KeyPadDisplay), and the value of the current button.
• The button’s label should be set to whatever the value was set to (e.g. KeyPadDisplay).
• Repeat the Append Variable for all the keys of the keypad. e.g. 0 - 9, *, and #
• Set up the KeyPadDisplay (variable) button, to display the numbers. Set the button’s Label Type value to
variable, then set the value to the variable: KeyPadDisplay.
• Launch the control screen to view and use the dial pad. To send the dialed number, see the SEND COMMAND
section.
Device - Variable Actions
Command - Append Variable
Device - System
Variable - (select relevant variable) e.g. KeyPadDisplay
Value - (enter the value to be added) e.g. 1
