Velocity
153
Custom Control Interface
Since there are 3 source buttons, use the green + button to add additional IF LOGICs for each variable value.
Select the Style tab and expand the Label section.
Select the variable Source from the drop down menu. This will
adjust the label to give the current variable value.
Select the Actions tab and expand the Conditions section.
Press the + button to add a new condition.
These conditions will provide a new look for the display button to
provide a visual representation of the selected source. The button
font, border, ll, and icon may be changed through conditions. The
button may also be hidden or disabled when the operator and value
of the condition are met.
Device - Logic Actions
Command Parameters - IF LOGIC
IF
Variable - (select a variable from drop down list)
e.g. Source
Operator - (select an operator from drop down list)
e.g. == (equals to)
Value - (Provide the variable value to match, that will
trigger the
THEN values)
e.g. Press to select Laptop
THEN
Run Macro - (Select from previously created macros)
e.g. Macro - Laptop
Set Variable - (set the new variable value here)
e.g. Laptop
Device - Logic Actions
Command Parameters - IF LOGIC
IF
Variable - (select a variable from drop down list)
e.g. Source
Operator - (select an operator from drop down list)
e.g. == (equals to)
Value - (Provide the variable value to match, that will
trigger the
THEN values)
e.g. Press to select Set Top Box
THEN
Run Macro - (Select from previously created macros)
e.g. Macro - Set Top Box
Set Variable - (set the new variable value here)
e.g. Set Top Box
Command 2
Command 3
