Velocity
151
Custom Control Interface
Macros & Variables Button Congurations
IF LOGIC
Extra macro options have been created to work with the custom UI buttons, to change variables and trigger
functions. The buttons can be used to trigger changes to volume, power, inputs, and more, using If Logic, If Else,
Send Commands, Decrement, Increment, and Append Variables macro values.
IF LOGIC provides programmable commands based on current settings. Some uses of the IF LOGIC may be to mute
or unmute audio, turn a display on or o, change sources, and much more.
The example below will provide examples of setting up and using a four button use case with three source buttons
and one display button. The Display button will adjust based upon the variable and condition options set up, in this
case, providing a way to conrm the source selection.
• Open the rst function button’s edit screen. e.g. BluRay
• Create a macro. The function SET VARIABLE may be used for labeling changes.
• Repeat the macro for all three source buttons.
Setting a label change on press, requires the following selections:
Device - Variable Actions
Command - SET VARIABLE
Device - (select a device from drop down list)
e.g. System
Variable - (select a variable from drop down list)
e.g. Source
Value - (set the new variable value here)
e.g. Press to select BluRay
BluRay Button
