Velocity
112
2. Select the Feature.
3. Select the room state in which the event occurs. For some options, room state is not applicable.
4. Set the command type, value, room, and repeat values for the feature.
5. Repeat steps 1 through 4 until all Event Macros are set up.
Macros & Conditions
Room On Event Macro:
With the room on macro, it can be set for open or split.
In this example set up, if Velocity sets the room to open or split, it will
trigger the event macro Room On and turn on all devices not excluded
in the Excluded On/O Devices section of the Room Control Options.
Apply Source Event Macro:
With the apply source macro, it can be set for a split room and which
side it occurs on.
In these examples, if Velocity is set to a split room, the UHD-CLSO-824
will be triggered to switch the source on the left side to Input 4 for Sony
Left (output 1) and on the right side to input 6 for Sony Right (output 2).
This will enable the change to occur automatically when split room is
enabled to provide a seamless switch between open closed rooms.
