Velocity

106

Macros & Conditions

• Custom Value - Select the check box to open up additional options and to add a new command for the

selected device within the room. The custom command is available in this current room only.

◊ HEX - Select if the command will be written in HEX rather than ASCII.

◊ Termination - Select the command termination from the drop down: CR, CRLF, LF, or none.

◊ Value - Type out the command exactly as the device’s manual/API writes it.

.

• : - use this option to delete, copy, or move the commands up or down. This allows for the commands to be

sent in the correct order needed, entered easily with similar commands, or removed when no longer needed.

.

• Repeat - Select how many times the command is sent out when the macro is selected within room control.

• Interval - Set the amount of milliseconds between when the command is rst sent and then repeated.

• Delay - Set the amount of time delay between the current command and the next command being sent.

Each macro can be programmed to send multiple commands, use the plus button next to the command name to

add a second command to the macro.

• Macro Name - The name of the macro will be used in Velocity to identify command on the back end. This

command, once saved, can be pulled up in other macros if needed.

• Device - Select the device that will be controlled with the macro. Only devices already added to the room

will be displayed in the device drop down menu.

• Command - Select the command from the drop down list available for the device. Device commands are

based o the device driver within Velocity. Velocity has built in commands that can be used for control.

Variables

Variables are functions that can be set and changed based on set events. They can

be created in the variables menu. View the Variables section under Custom Control

Interface for more information on how to create variables.
