AT-UHD-PRO3-44M
9
The AT-UHD-PRO3-44M is an HDMI to HDBaseT matrix switcher with PoE for 4K/UHD @ 60 Hz video signals with
Power over Ethernet for receivers and analog audio breakout. The matrix provides both extended distance, 330
foot (100 meter) and long distance, 230 foot (70 meter) HDBaseT transmission over category cable. It also provides
convenient bidirectional extension of both RS-232 and IR Control. An HDMI output is provided as a mirrored output
designed for routing HDMI-based audio to an AVR or as an additional matrix output. The matrix switcher is HDCP 2.2
compliant and supports EDID communication. The matrix is control system-friendly and integrates with any TCP/IP,
RS-232, or IR based control signals. Designed for multi-zone residential or commercial distribution applications, the
PRO3-44M features a 1U, rack-mountable enclosure with an internal, international power supply.
Features
Package Contents
• Four HDMI inputs
• Four HDBaseT outputs with 330 foot (100 meter) and 230 foot (70 meter) transmission of HDMI, power, and
control
• HDMI output with independently-selectable mirror and matrix modes
• 4K/UHD capability @ 60 Hz with 4:2:0 chroma subsampling
• HDCP 2.2 compliant
• Audio de-embedding with volume, mute, and ve-band EQ
• PoE (Power over Ethernet) source - remotely powers compatible HDBaseT endpoints
• TCP/IP, RS-232, and IR control
1 x AT-UHD-PRO3-44M
14 x 4-pin captive screw connectors
1 x 5-pin captive screw connector
1 x IEC power cable
2 x 19” mounting brackets
1 x Installation Guide
Introduction
