AT-UHD-PRO3-44M
29
Basic Operation
Creating and Editing Routing Presets
1. Login to the web GUI. Refer to Introduction to the Web GUI (page 53) for more information.
2. Click Route Memory, under the Conguration section, in the menu bar on the left side of the screen.
3. Create the desired routing state(s). Video and audio routing is similar to the I/O screen. Refer to Routing Inputs
to Outputs (page 21).
4. Click the drop-down list, next to each output, to set the desired routing state. In this example below, Preset_2
will be used to store the current routing state. The Mirror Mode drop-down lists can also be changed as
desired, and will be stored as part of the routing preset.
5. Click the Save button to commit changes.
Creating a Routing Preset
Using presets provides a quick and ecient way of switching between multiple routing congurations. The AT-
UHD-PRO3-44M provides 50 memory locations that can be used to store each preset. The following section covers
creating, editing, and using routing presents.
