This procedure will route a single input to all ve outputs.
4. Press the button for the desired input. In this example, HDMI IN 2 is selected by pressing button 2. The front
panel display will conrm the current routing selection.
Basic Operation
Select input to
route to all outpuTs
input 02 saved to
all outpuTs
3. Press button 1 to execute the Route To All Outputs function.
Routing a Single Input to All Outputs
1. Make sure the home screen is displayed. If the home screen is not displayed, press the CANCEL button to
return to the home screen.
2. Press and release the FNC button to display the Select Function screen.
Using the Front Panel
RX
TX
S
OFF
ON
2 3 4 21 3 41
L
1
R
2
L R
3
L R
1ED
2
3
4 5
1 2
3 4
IR OUT
PWR: 100-240VAC 50/60Hz
IR IN
S
S
S S S
S S
S
AUDIO OUT
HDMI IN
ZONE OUTIR IN LAN
FW
RS-232
EDID
POWER ENTER
FNC CANCEL INFO
1
2 3
4
5
AT-UHD-PRO3-44M
