AT-UHD-CLSO-840
73
Appendix
The AT-UHD-CLSO-840 can be placed on top of any at surface. To prevent damage to the surfaces or unnecessary
movement of the matrix, four feet have been included.
1. Turn the unit upside down.
2. Install each foot using the included feet screws, the rubber grips of the feet should be facing up during
installation.
3. Turn the unit right-side up and place it in the desired location.
Surface Mounting
