Specifications
Video Resolutions
IN 4096x2160@24/25/30, 3840x2160@24/25/30 (UHD), 2048x1080p,
1080p@23.98/24/25/29.97/30/50/59.94/60Hz, 1080i@50/59.94/60Hz, 720p@50/59.94/60Hz,
576p, 576i, 480p, 480i
2560x2048, 2560x1600, 2048x1536, 1920x1200, 1680x1050, 1600x1200, 1600x900,
1440x900, 1400x1050, 1366x768, 1360x768, 1280x1024, 1280x800, 1280x768, 1152x768,
1024x768, 800x600, 640x480
OUT 4096x2160@24/25/30, 3840x2160@24/25/30 (UHD), 2048x1080p,
1080p@23.98/24/25/29.97/30/50/59.94/60Hz, 1080i@50/59.94/60Hz, 720p@50/59.94/60Hz,
576p, 576i, 480p, 480i
2560x2048, 2560x1600, 2048x1536, 1920x1200, 1680x1050, 1600x1200, 1600x900,
1440x900, 1400x1050, 1366x768, 1360x768, 1280x1024, 1280x800, 1280x768, 1152x768,
1024x768, 800x600, 640x480
Composite/S-Video NTSC, NTSC4, PAL, PAL-M, PAL-N, SECAM
Colorspace YUV, RGB
Chroma Subsampling 4:4:4, 4:2:2, 4:2:0 (UHD only)
Color depth 8-bit, 10-bit, 12-bit
Nominal Level Composite: (1 Vp-p), S-Video: Y(1Vp-p) - C(0.3 Vp-p)
Component: Y(1Vp-p) - Pb(0.7 Vp-p) - Pr(0.7 Vp-p), VGA: R(0.7 Vp-p) - G(0.7 Vp-p) - B(0.7 Vp-p)
Min/Max levels Analog: 0.0V to 1.0 Vp-p wit no offset at unity gain
Impedance 75 ohms
Horizontal Frequency 15kHz to 100kHz
Vertical Frequency 24Hz to 120Hz
Audio
Analog Output PCM 2Ch (de-embedded)
HDMI/HDBaseT Output PCM 2Ch, LPCM 5.1, LPCM 7.1, Dolby Digital, DTS 5.1, Dolby Digital Plus,
Dolby TrueHD, DTS-HD Master Audio, Dolby Atmos, DTS:X
Frequency Response 20Hz to 20KHz ±1db
THD + Noise <0.01%, 20Hz to 20kHz at nominal level
S/N ≤ -68dB @ 1kHz, fully loaded
Bass +15dB to -12dB @ 250Hz
Treble +15dB to -12dB @ 3kHz
Distance
CAT5e/6 @ 4K up to 70M up to 230 ft
CAT6a/7 @ 4K up to 100M up to 328 ft
CAT5e/6 @ 1080p up to 100M up to 328 ft
HDMI IN/OUT @ 4K up to 5M up to 15 ft
HDMI IN/OUT @ 1080p up to 10M up to 30 ft
Signal
Bandwidth 10.2 Gbps
CEC Compliant
HDCP Switchable - Compliant / Non compliant - 1.4
Temperature
Operating 0°C to 50°C 32°F to 122°F
Storage -20°C to 60°C -4°F to 140°F
Humidity 20 to 90% non-condensing
Power
Consumption 43W
Idle Consumption 4W
Supply Input: AC100-240V ~ 50/60Hz
Output: DC 48V/3.125A
Dimension
H x W x D 44 x 438 x 254 (mm) 1.73 x 17.24 x 10 (inch)
Rack Unit 1U
Weight
Device 3.22 kg 7.10 lbs
Certification
Unit CE, FCC
Power Supply CE, FCC, Level VI, RoHS, cULus, RCM, CCC
