AT-UHD-CAT-4
8
4. Connect an Ethernet cable from the LAN port to the Local Area Network (LAN). This step will be required in order
to access the built-in web server.
5. Connect the included power supply to the DC 48V connector and connect the power cord to an available
electrical outlet.
6. Connect an RS-232 or IR cable from the control system to the RS-232/IR ports. Refer to RS-232 Control (page
19) and IR Control (page 23) for more information.
• MASTER RS-232/IR
Connecting to this port will provide direct control of the AT-UHD-CAT-4 using a control system. Control can
be performed using either RS-232 or electrical IR.
• RS-232/IR 1 through RS-232/IR 4
Each of these ports is associated to the respective HDBaseT OUT port. This allows RS-232 pass-through
zone control of a display (sink) device that is connected to a PoE-compatible receiver. Control can be
performed using RS-232 or electrical IR.
1. Connect an HDMI cable from a UHD/HD source to the HDMI IN port.
2. Connect an HDMI cable from the HDMI OUT port to a display (sink) device.
3. Connect up to four Ethernet cables from the HDBaseT OUT ports to compatible PoE-capable receivers. Refer to
the table below for information on maximum cable length and supported resolutions.
Connection Instructions
IMPORTANT: Stranded or patch cable is not recommended due to performance issues.
Shielded cables are strongly recommended to minimize signal noise and interference.
Installation
Cable 4K/UHD - Feet / Meters 1080p - Feet / Meters
HDMI 15 5 30 10
CAT5e/6 115 35 200 60
CAT6a/7 130 40 230 70
