AT-UHD-CAT-4
6
The Atlona AT-UHD-CAT-4 is a 4K/UHD HDMI to HDBaseT distribution amplier featuring pass-through HDMI input
connections, four HDBaseT outputs and display control capability. Each output transmits AV and control signals
up to 230 ft. (70 m) @ 1080p and 130 ft. (40 m) @ 4K/UHD. Features include 4K/UHD @ 60 Hz with 4:2:0 color
subsampling, HDCP 2.2 compliance, EDID management, and PoE for powering remote receivers. A wide variety
of consumer displays may be controlled by the UHD-CAT-4 using CEC*. Designed for commercial distribution
applications, the UHD-CAT-4 is control system-friendly and integrates with any TCP/IP, RS-232, or IR control system
and features a 1U, half-rack width enclosure with external, international power supply. Compatible Atlona receiver:
AT-UHD-EX-70C-RX.
Introduction
Features
Package Contents
• HDMI distribution amplier with built-in HDBaseT transmission
• Four HDBaseT outputs for transmission of HDMI, Ethernet, and control up to 230 feet (70 meters)
• 4K/UHD capability with HDCP 2.2 copy protection
• Power over Ethernet (PoE) for HDBaseT receivers
• CEC display control
• Multi-channel audio compliant
• EDID management
• Intuitive GUI-based conguration using integrated web server
• TCP/IP, RS-232, and IR control
• Easy to congure and manage with AMS (Atlona Management System)
• Field-updatable rmware
• Front panel power and signal status LEDs
• Rack-mountable 1U, half rack width enclosure
• Award-winning 10 year limited product warranty
1 x AT-UHD-CAT-4
1 x IR emitter (AT-IR-CS-TX)
3 x 5-pin captive screw connector
2 x Mounting Plates
1 x Rack Ear (long)
1 x Rack Ear (short)
4 x Screws (MAS-MF03+04D1 for Mounting Plate)
4 x Screws (MAS-MF04+06D for Rack Ear)
1 x 48 V / 2.08 A power supply
1 x AC cord
1 x Installation guide
*Consumer Electronics Control (CEC): Atlona has conrmed proper CEC functionality with several current models of Samsung, Panasonic, and
Sony displays. However, it is not guaranteed that CEC will work with all displays. Many manufacturers do not support the CEC “o” command,
and older displays use proprietary commands. Atlona only supports displays that use the CEC command structure dened in HDMI 1.2a. It is
recommended that dealers request an evaluation product from Atlona, before designing a system using the CEC protocol. If this is not possible,
then other control methods will need to be considered, in order to control displays using Atlona products.
