AT-UHD-CAT-2
6
The Atlona AT-UHD-CAT-2 is a 4K/UHD HDMI to HDBaseT distribution amplier featuring a pass-through HDMI
output, two HDBaseT outputs and display control capability on all three outputs. Each output transmits AV and
control signals up to 230 ft. (70 m) @ 1080p and 130 ft. (40 m) @ 4K/UHD. Features include 4K/UHD @ 60 Hz with
4:2:0 color subsampling, HDCP 2.2 compliance, EDID management, and PoE for powering remote receivers. A wide
variety of consumer displays may be controlled by the UHD-CAT-2 using CEC*. Designed for commercial distribution
applications, the UHD-CAT-2 is control system-friendly and integrates with any TCP/IP, RS-232, or IR control system
and features a 1U, half-rack width enclosure with external, international power supply. Compatible Atlona receiver:
AT-UHD-EX-70C-RX.
Introduction
Features
Package Contents
• 4K/UHD capability @ 60 Hz with 4:2:0 chroma subsampling
• HDCP 2.2 compliant
• HDMI® distribution amplier with built-in HDBaseT
TM
transmission up to 230 feet (70 meters)
• HDMI input with pass-though
• Two HDBaseT outputs
• PoE (Power over Ethernet) source – remotely powers PoE-compatible receivers
• Transmits RS-232, IR, and CEC control signals over HDBaseT
• Triggered display control using Consumer Electronics Control (CEC)
1 x AT-UHD-CAT-2
1 x IR emitter (AT-IR-CS-TX)
3 x 5-pin captive screw connector
2 x Mounting Plates
1 x Rack Ear (long)
1 x Rack Ear (short)
4 x Screws (MAS-MF03+04D1 for Mounting Plate)
4 x Screws (MAS-MF04+06D for Rack Ear)
1 x 48 V / 2.08 A power supply
1 x AC cord
1 x Installation guide
*Consumer Electronics Control (CEC): Atlona has conrmed proper CEC functionality with several current models of Samsung, Panasonic, and
Sony displays. However, it is not guaranteed that CEC will work with all displays. Many manufacturers do not support the CEC “o” command,
and older displays use proprietary commands. Atlona only supports displays that use the CEC command structure dened in HDMI 1.2a. It is
recommended that dealers request an evaluation product from Atlona, before designing a system using the CEC protocol. If this is not possible,
then other control methods will need to be considered, in order to control displays using Atlona products.
