AT-OMNI-311
19
Basic Operation
7. Click the Save icon in the top-right portion of the Room Macros bar.
8. Create a “pairing” macro by clicking the icon, in the upper-right corner of the screen.
Note that since there are two AT-OMNI-324 units, creating the “Pair” macro can be achieved using two dierent
methods:
a. Create two separate macros: one to pair the AT-OMNI-311 and the AT-OMNI-324 with the camera, and
another one to pair the AT-OMNI-311 with the AT-OMNI-324 with the speakerphone. This method provides
more control, providing the option of which AT-OMNI-324 is paired with the AT-OMNI-311.
b. Create a single macro which pairs both AT-OMNI-324 units to the AT-OMNI-311. This method is more
convenient, but does not provide the option of which AT-OMNI-324 is paired with the AT-OMNI-311.
For this example, two separate pairing macros will be created:
9. Enter “Pair to camera” in both the Name and Macro Commands text eld. This macro will be used to pair the
computer with the camera.
10. Click the + icon to display the macro conguration dialog.
11. Click the Device drop-down list and select the AT-OMNI-324 that is connected to the camera. In this example,
the AT-OMNI-324 with the IP address of 192.168.11.124 will be selected.
12. Click the Command drop-down list and select Pair (Auto).
13. Click the second Device drop-down list and select the AT-OMNI-311.
14. Repeat steps 10 through 13: select the AT-OMNI-311 in the rst Device drop-down list, and then the AT-
OMNI-324 with the camera, from the second Device drop-down list. The “Pair to camera” macro should now
appear as follows:
+
