SPECIFICATION
Model Name AT-HD14SS AT-HDRS AT-HD15SRS
Technical
Role of usage
1x4 Distribution Amplifier
Transmitter [TX]
Receiver
[long range RX]
Receiver
[short range RX]
HDMI compliance HDMI 1.3c
HDCP compliance Yes
Video bandwidth Single-link 225MHz [6.75Gbps]
Video support 480i / 480p / 720p / 1080i / 1080p60
Transmission
Full HD (1080p): 40m (130ft) [CAT5e] / 50m (165ft) [CAT6]
HD (720p/1080i): 50m (165ft) [CAT5e] / 60m (200ft) [CAT6]
Audio support Surround sound (up to 7.1ch) or stereo digital audio
Equalization N/A 8-level digital None
Input TMDS signal 1.2 Volts [peak-to-peak]
Input DDC signal 5 Volts [peak-to-peak, TTL]
ESD protection
[1] Human body model — ±15kV [air-gap discharge] & ±8kV [contact discharge]
[2] Core chipset — ±8kV
Input 1x HDMI 1x RJ-45 1x RJ-45
Output 4x RJ-45 1x HDMI 1x HDMI
HDMI connector Type A [19-pin female] Type A [19-pin female]
Type A [19-pin male]
RJ-45 connector WE/SS 8P8C with 2 LED indicators
Mechanical
Housing Metal enclosure Metal enclosure Plastic molding
Dimensions
[L x W x H]
Model
215 x 85 x 40mm
[8.5” x 3.3” x 1.6”]
80 x 60 x 25mm
[3.2” x 2.4” x 1”]
45 x 25 x 20mm
[1.8” x1” x 0.8”]
Package
330 x 200 x 95mm
[1’1” x 7.9” x 3.7”]
270 x 175 x 80mm
[10.6” x 6.9” x 3.2”]
170 x 115 x 40mm
[6.7” x 4.5” x 1.6”]
Weight
Model
525 [1.2 lb]
154g [5oz] 22g [1oz]
Package
985 [2.2 lb]
453g [1 lb] 90g [3oz]
Fixedness Wall-mount with ears Wall-mount case Direct plug-in
Power supply 5V DC 5V DC None
Power consumption 10 Watts [max] 1 Watt [max] 0.5 Watt [max]
Operation temperature
0~40°C [32~104°F]
Storage temperature
-20~60°C [-4~140°F]
Relative humidity 20~90% RH [no condensation]
