AtlasSound.com – 6 –
ECM-15SH
AC
Power Conditioner & Suppression Module
1601 Jack McKay Blvd. • Ennis, Texas 75119 U.S.A.
Telephone: 800.876.3333 • Fax: 800.765.3435
Internal Features of the ECM-15SH – Protection behind the panel
• EMI/RFI Filters – ECM filters for unwanted Radio Frequency Interference (RFI) that is commonly introduced into the AC
lines by nearby radio transmitters or wireless products. EMI filters are incorporated to reduce noise from Electromagnetic
Interference (EMI) produced by such items as electric motors, switching power supplies and lightning. The benefit of these filters
can be seen on video products or audibly by reducing static pops and external signal interference.
• AC Spike Protection - ECM modules feature AC spike suppression. AC Spikes, or Transients, are commonly caused by lightning
storms or utility power plant grid switchovers. The amount of energy that can be injected into the power system can be immense
with voltages reaching 6KV or amperage peaks of 3000A. These spikes are very fast and usually only last for a very short period of
time. To protect against this potential problem, incoming AC Mains have special suppression circuitry to eliminate the unwanted
energy. This circuitry is very fast and can suppress unwanted energy within a nanosecond, while sustaining the suppression up to 2
milliseconds, thus ensuring virtually trouble free protection.
• AC Surge Protection - High line can also be known as surges. Surges usually are a slower steady state rise in voltages ranging from
128VAC and up. They can be caused by fluctuations in the utility company's power lines or industrial equipment turning on
and off, and are on the same power leg of the building's incoming AC.
• EVS Protection – If an ECM Module is connected to the ECS-6RM, the ECS-6RM has built in intelligence that monitors the AC lines
from the ECM modules and will inform you of potentially damaging voltages. If the AC Mains voltage is between 128VAC
and 132VCA or 107VAC and 101VAC the display will flash an error code indicating a potential fault has occurred and you should
check sensitive equipment. If an extreme voltage swing occurs above 128VAC or below 101VAC, the Extreme Voltage Shutdown
(EVS) protection circuit will automatically turn all remote ECM modules off until the system is manually reset. The EVS feature can
be defeated if required via the ECS-6RM EVS bypass switch.
• Over Current Protection – In the case of excessive current draw at the ECM module, an internal Slow Blow fuse will open
and protect the devices plugged into the ECM module. Note: This fuse must be changed by a qualified service technician.
ECM Data Wire and Distance
The ECM-15SH is one of four different types of ECM Modules requiring the same interface connectivity to the ECS-6RM. All ECM
Modules can be interfaced with the ECS-6RM. For connection between the ECS-6RM and an ECM module, use a 5 conductor cable
that is a minimum of 22-gauge wire. We suggest using CAT5 cable due to the common availability and low cost. Heavy gauge wire or
cable with a high voltage rating are not needed because the data signal and supply voltage are low current. Pay special attention to the
port connections and DO NOT MISS WIRE or damage may occur. The distance between the ECS-6RM and the ECM Module can be up
to 1000'.
