INSTALLATION GUIDE
YOKE MOUNT / C-BRACKET
AS Series
TOOLS REQUIRED / PACKAGE CONTENTS
AS Series Surface Mount Loudspeakers: Included Contents / Required Tools
PART DETAIL QTY PART NUMBER (W) PART NUMBER (B)
Yoke Bracket (C-bracket) 1
Yoke loudspeaker tightening screws Button head ange M6x1 316SS 2 1-9410
Yoke screw cover caps 2 1-18740 1-18820
Cable cover screws; SCREW-M4x1.46-17MM
L-PLASTITE-FH-PH H2-SST-BLACK
4 1-19361
Grommet; GROMMET-WATER SEAL-REAR-AS
LOUDSPEAKER
1 1-17159
Cover; COVER-WATER SEAL-AS LOUDSPEAKERS 1 1-19150
Mounting plate; PLATE-MOUNTING CABLE COVER-
REAR-AS
1 1-19117
4-pin Euroblock connector 5mm pitch 1 1-19353
Loudspeaker Cover - Speaker ‘teeth’ cover 2 1-18569
Yoke bracket endcap/covers 2 1-18740 1-18820
REQUIRED TOOLS
1. Electric Drill
2. Slotted screwdriver: 3.5mm
3. Drill bit: #1 = 0.2280”; use #1 bit or smaller depending on the size of wire used Phillips screwdriver (optional weatherproong)
4. Wire strippers
