Chapter 2. Hardware Setup
11
Setting Up
Setting up the VE813A HDMI Extender system is simply a matter of plugging
in the cables. Make sure that all the equipment to be connected are powered off.
Refer to the installation diagram on the following page and do the following:
1. Connect the USB cable supplied with the package to the USB Type B port
on the Transmitter (VE813AT). Plug the other end of the cable into a USB
Type A port on the source device.
2. Connect the HDMI cable supplied with the package into the HDMI input
port located on the Transmitter (VE813AT). Plug the other end of the
cable into the HDMI port on the source device.
3. Use a Cat 5e cable to connect the Unit to Unit port on the Transmitter
(VE813AT) to the Unit to Unit port on the Receiver (VE813AR).
4. Plug one of the power adapters (supplied with this package) into a power
source; plug the adapter's power cable into the VE813AT’s Power Jack.
5. Use an HDMI cable to connect the HDMI output port on the Receiver
(VE813AR) to the HDMI display.
6. Plug the cables from the USB devices (mouse, keyboard, flash drive,
printer, scanner, web cam, etc.), into their respective USB ports on the
Receiver (VE813AR).
7. Plug the second power adapter (supplied with this package) into a power
source; plug the adapter's power cable into the VE813AR’s Power Jack.
