1
Chapter 1
Introduction
Overview
KX9970 / KX9970F
The KX9970 / KX9970F 5K DisplayPort Single Display KVM over IP
Extender consists of a high performance IPbased transmitter (KX9970T /
KX9970FT) and a receiver (KX9970R / KX9970FR), where the transmitter
can transmit a computer’s keyboard, video, mouse, and USB signals to the
receiver for providing separate console accesses from both the transmitter’s
and receiver’s locations. The setup allows extended access to computer
systems via a USB console (USB keyboard, USB mouse, DisplayPort monitor)
over Intranet, enabling users to place the computers in secure and temperature-
controlled environments, which may be isolated from the user workstation.
The KX9970 / KX9970F each support one DisplayPort video display for
delivering video resolutions of up to 5K (5120 x 2880 @ 30 Hz), and offer
flawless and lossless video quality with extremely low latency. Each KX9970
extender model is equipped with one RJ-45 port and two SFP+ slots while
KX9970F is only equipped with two SFP+ slots. 10-Gbps SFP+ fiber module
expansions are supported for fiber optic network connections and a
transmission distance of up to 10 km. For connection flexibility, both the
KX9970 transmitter and receiver models can be connected either directly to
each other or via a high-speed network over a copper-based or fiber-based
LAN. The KX9970 / KX9970F also features dual power supply capability for
power redundancy to ensure reliable services. The KX9970 / KX9970F can be
set up at the workstation, mounted onto a wall or at the rear of a rack with its
space-saving 0U rack-mount design.
As an IP-based matrix extender, the KX9970 / KX9970F can be installed in
flexible configurations, including point to point, point to multipoint, multipoint
to point, and multipoint to multipoint. When combined with the KVM over IP
Matrix Manager (CCKM), it can be integrated into a KVM over IP matrix
system (multipoint-to-multipoint) for providing more flexible applications in
different working environments.
By integrating CCKM with KX9970 / KX9970F, IT administrators can benefit
from advanced features such as auto detection of all KX9970 / KX9970F
devices on the same subnet for the sake of fast installation or configuration,
