Chapter 1. Introduction
9
No. Component Description
1 Port Selection
Pushbuttons
Press a pushbutton to give the KVM focus to the computer
attached to its corresponding port.
Simultaneously pressing pushbuttons 1 and 2 for 3 seconds
performs a Keyboard and Mouse Reset.
Simultaneously pressing pushbuttons 15 and 16 starts Auto
Scan Mode.
2 Port LEDs The Port LEDs are built into the Port Selection Pushbuttons. The
left ones are the On Line LEDs; the right ones are the Selected
Port LEDs:
An ONLINE LED lights GREEN to indicate that the computer
attached to its corresponding port is up and running. A flashing
LED indicates that the Port is being used for cascading to
another switch.
A SELECTED LED lights ORANGE to indicate that the computer
attached to its corresponding port is the one that has the KVM
focus. The LED is steady under normal conditions, but flashes
when its port is accessed under Auto Scan Mode.
3 Reset Switch Pressing this switch in performs a system reset.
Note: The switch is recessed and must be pushed with a thin
object - such as the end of a paper clip, or a ballpoint pen.
4 Laptop USB
Console Port
This mini-USB port allows a laptop to be connected for local
access and control. See Laptop USB Console Login, page 52 for
further details.
5 Firmware
Upgrade
Recovery
Switch
During normal operation and while performing a firmware upgrade,
this switch should be in the NORMAL position. If a firmware
upgrade operation does not complete successfully, this switch is
used to perform a firmware upgrade recovery.
6 Firmware
Upgrade Port
The Firmware Upgrade Cable that transfers the firmware upgrade
data from the administrator's computer to the KH1508Ai / KH1516Ai
(see page 36), plugs into this RJ-11 connector.
7 Power LED Lights to indicate that the KH1508Ai / KH1516Ai is powered up and
ready to operate.
8 Station ID LED The KH1508Ai / KH1516Ai's Station ID is displayed here. If this is a
Single Station installation (see page 16), or the First Station on a
Daisy Chained installation (see page 20), the KH1508
Ai /
KH1516
Ai has a Station ID of 01.
On a Daisy Chained installation, the KH1508
Ai / KH1516Ai auto-
senses its position and displays the Station ID that corresponds to its
place in the chain. (see Port ID Numbering, page 25, for details).
