Chapter 5. OSD Operation
73
Display Aspect Ratio Full / 16:9 / 4:3 Sets the display aspect ratio for Quad,
PbP (Dual), PbP (Triple), and PbP
(Quad) display modes. For more
information, see Configuring the
Display Aspect Ratio, page 54.
Window Frame Disable / 3 secs / 5
secs / 10 secs / always
on
Sets the duration for Window Frame.
Note: Hardware Cursor Mode must be
enabled, see The OSD Menu, page 69.
Port Configuration
Port 1 Name PC1 Type to name the computers
connected to port 1 / port 2 / port 3 /
port 4 on the Multi-View KVMP™
Switch. The Multi-View KVMP™ Switch
only supports English characters of
upper and lower cases, numbers,
hyphens, and underscores.
Port 2 Name PC2
Port 3 Name PC3
Port 4 Name PC4
Port 1 OS Win / Mac / SUN / SPC
Defines the operating system for each
of the connected computers.
Port 2 OS Win / Mac / SUN / SPC
Port 3 OS Win / Mac / SUN / SPC
Port 4 OS Win / Mac / SUN / SPC
Advanced
Expansion Chain Std / Chain Horz
/ Chain 2 x 2 / Chain
Vert / Cascade
Sets the Multi-View KVMP™ Switch’s
deployment type. For more information,
see Multiview Monitor Layout Rule,
page 35.
Chain Horz: Sets a row layout for
daisy-chained monitors.
Chain 2 x 2: Sets a quarter layout
for diasy-chained monitors.
Chain Vert: Sets a tier layout for
daisy-chained monitors.
Note: Hardware Cursor Mode must be
enabled, see The OSD Menu, page 69.
Control Station Station 1 / Station 2 /
Station 3 / Station 4
This setting is only available when
Expansion is set to Daisy Chain.
Select a daisy-chained secondary
station for keyboard and mouse
control.
Setting Options Description
