Multi-View KVMP™ Switch User Manual
72
HSM [Num][-] / [Ctrl][F12] Defines the hotkey combination for
enabling the Hotkey Setting Mode
(HSM).
Menu Hotkey Scroll*2 / Ctrl*2 Sets the hotkey combination for
opening the menu.
Extended Desktop Enable / Disable Enable this function for Multi-View
KVMP™ Switch to extend desktop and
make extended desktops configuration.
Display
Channel Info Enable / Disable Enable this setting to display port ID
numbers and device names.
Multiview Mode Single / Quad / PiP2 /
PiP3 / PiP4 / PoP /
PbP1 / PbP2 / PbP3 /
Fn1 / Fn2 / Fn3 / Fn4
Sets or changes the display mode for
the Multi-View KVMP™ Switch. For
details about each display mode, see
Extended Desktops, page 37.
Channel 1 Port 1 / Port 2 / Port 3 /
Port 4 Sets the source assignment for each
channel. For example, if you select
Port 2 for Channel 1, port 2 source will
be displayed on Channel 1, and port 1
source will be displayed at Channel 2.
Channel 2 Port 1 / Port 2 / Port 3 /
Port 4
Channel 3 Port 1 / Port 2 / Port 3 /
Port 4
Channel 4 Port 1 / Port 2 / Port 3 /
Port 4
Save to Fn Fn1 / Fn2 / Fn3 / Fn4 Saves the view mode settings to the
selected Function mode.
Toolbar Position Top / Bottom Sets the position of the Quick Access
Toolbar.
Transparency Enable / Disable Enable this setting to make the inset
window(s) of a PiP display semi-
transparent.
Note: This setting only applies to the
built-in PiP2, PiP3, and PiP4 modes.
Port 1 No Group / GroupA:
Main / GroupA: Ext. /
GroupB: Main /
GroupB: Ext.
Sets the layout position for the
extended desktops function. For more
information, see Extended Desktops
Layout Positions, page 40.
Port 2
Port 3
Port 4
Setting Options Description
