Multi-View KVMP™ Switch User Manual
68
4. Configure and adjust the display as required. You can do the following
when the editor mode is enabled:
Note: When the editor mode is enabled, the OSD Menu will not be
accessible and the hotkeys functionality will be disabled.
5. When you finish configuring, click
to quit the editor mode.
Function Action
Change the display mode
Click a display mode from the Quick Access
Toolbar.
Click to display the window in full screen.
Apply a preset configuration Click an Fn icon from the Quick Access Toolbar. For
more information, see Configuring the Display
Aspect Ratio, page 54.
Swap locations of video
sources in quad mode
Click the port number at the top left corner and
select a port.
Note: Under 4K resolution, to use this function in a
Quad view, make sure port 1 and 2, port 3 and 4 are
next to each other.
Resize windows Click on a window, move the cursor to a corner of
the window, and drag the corner to resize the
window.
Note: Under 4K resolution, red zones appear to
indicate the resized window exceeds the restricted
limits.
Relocate windows Click and hold on a window to drag it to a desired
location on the screen.
Note: Under 4K resolution, red zones appear to
indicate restricted areas for the dragged window.
Set windows to the front or
the back
When two windows overlap, you can configure
which one appears on top of the other. To bring a
window on top of the other, click the window, and
then click . Click to send the selected
window to the back.
Reset
Click to reset all the port location and size back
to default settings.
