Single Board Computer 49
To install an M.2 2280 SSD:
1. (Optional) If a wireless card is installed, remove the screw holding it in
place (A), replace it with a standoff (B), and skip to step 3.
NOTE: We recommend using a PH1/sleeve screwdriver with a torque of
2.0±0.2kgf-cm when tightening the stando.
2. (Optional) Replace the standoff if it was removed.
NOTE: We recommend using a PH1/sleeve screwdriver with a torque of
2.0±0.2kgf-cm when tightening the stando.
3. Align and insert the M.2 SSD into its slot inside the Single Board
Computer.
4. Gently push down the M.2 SSD on top of the standoff and fasten it
using a screw.
NOTE: We recommend using a PH1 screwdriver with a torque of
2.0±0.2kgf-cm when tightening the screw.
