2-3
Chapter 2: Setup
2.3 Detaching the base (for VESA wall mount)
The detachable arm/base of this monitor is specially designed for VESA
wall mount.
To detach the arm/base:
1. Disconnect power and signal cables. Then, by aligning the monitor
closer to the edge of the table, carefully place the monitor on the EPE
bag, with the screen facing down.
2. Remove the hinge cover.
3. Push the latch to disengage the arm hinge of the the stand assembly.
Then pull to remove the stand assembly.
4. Align and install the wall mount bracket on the rear of the monitor.
Screw holes for VESA wall mount
(75 x 75 mm)
• We recommend that you cover the table surface with soft cloth to prevent
damage to the monitor.
• Hold the base while removing the screw.
• The VESA wall mount kit (75 x 75 mm) is purchased separately.
• Use only the UL Listed Wall Mount Bracket with minimum weight/load
22.7kg(Screwsize:M4x10mm).
