2-1
ASUS TUF Gaming Monitor VG27AQML5A Series
2.1 Assembling the monitor arm/base
To assemble the monitor base:
1. Have the front of the monitor face down on a table.
2. Align and install the arm hinge of the stand assembly onto its
compartment on the rear of the monitor. Fix the arm hinge to the
monitor with the screw(s). Then place the rubbers on top of the
screw(s) (Figure 1)
3. Attach the base into the arm, making sure the tab on the arm ts into
the groove on the base. (Figure 2)
4. Fix the base to the arm by fastening the bundled screw(s). (Figure 3)
We recommend that you cover the table surface with soft cloth to prevent
damage to the monitor.
1
2
1
2
1
2
1
(Figure 1) (Figure 2)
(Figure 3)
• Hinge screw size: M4 x 8 mm.
• Base screw size: M6 x 16.2 mm.
