Industrial motherboard
R23141-IM-A Specifications Summary
(continued on the next page)
R23141-IM-A
Processor
APU AMD Ryzen™ Embedded R2314 2.1GHz Quad-core
Chipset
Integrated
Memory
Technology DDR4 2667MHz (one package rank) / 2400MHz (two package ranks), ECC support
Max.
32GB
Socket
2 x SO DIMM
Graphics
Display Port
3 x DP++ supports DisplayPort 1.4 with max. resolution 3840 x 2160 @ 60 Hz
1 x DP++ supports DisplayPort 1.4 with max. resolution 3840 x 2160 @ 60 Hz
(Optional, shared with LVDS and eDP)*
LVDS (default option)
1 x LVDS supports LVDS with max. resolution 1920 x 1200 @ 60 Hz (Optional, shared
with DisplayPort1 and eDP)
eDP (optional)
1 x eDP supports eDP 1.3 with max. resolution 3840 x 2160 @ 60 Hz (Optional,
shared with DisplayPort1 and LVDS)
Multi Display
Default: 4DP
Optional: 3DP+LVDS / 3DP+eDP
Supports up to 4 displays simultaneous under OS
Expansion slot
PCIe
1x PCIe 3.0 p8-x8 slot
(support p8-x8 interface and 25W power dissipation)
M.2
1 x M.2 (key M 2242 / 2260 / 2280) PCIe p8-x2 (NVME) / SATA
1 x M.2 E key for PCIe / USB 2.0 support 2230 (width up to 22 mm)
Ethernet
Speed 10/100/1000Mbps
Controller
2 x Realtek® 8111H
Connector
2 x RJ45
Audio
Codec Realtek® ALC897 codec
Connector
1 x 5.1 channel (Internal pin header)
Storage
Option 1 (Default):
- 1 x SATA port Gen 3.0, up to 6Gb/s
- 1 x M.2 (Key M, 2242 / 2260 / 2280) PCIe p8-x2 and SATA mode*
- 1 x CFAST*
* If CFAST is enabled, M.2 SATA mode will be disabled, and vice versa. You may configure this setting in
the BIOS.
Option 2 (per request):
- 2 x SATA port Gen 3.0, up to 6Gb/s
- 1 x M.2 (Key M, 2242 / 2260 / 2280) PCIe x2
Rear I/O
3 x DisplayPorts
1 x Additional display output port (LVDS*, DisplayPort, or eDP)
2 x USB 3.2 Gen 2 Type A ports
2 x USB 2.0 ports
2 x Ethernet ports
2 x COM connectors
(RS232 / 422 / 485)
1 x Mic in + Line out jack
1 x DC-in jack
* Default option.
