Industrial motherboard
27
15. Serial Port connector
The Serial (COM) Port connector allows you to connect a serial port module. Connect the serial port
module cable to this connector, then install the module to a slot opening on the system chassis.
Connector type
BOX header 2x5p, K10, 2.0mm pitch
NOTE:
• The serial port module is purchased separately.
• COM1 and COM2 support RS-232/422/485.
• COM 3, COM4, COM5, and COM6 support RS-232.
16. USB 2.0 header
The USB 2.0 header allows you to connect a USB module for additional USB 2.0 ports. The USB 2.0
connector provides data transfer speeds of up to 480 MB/s connection speed.
Connector type
BOX header 2x5p, K9, 2.0mm pitch
WARNING! DO NOT connect a 1394 cable to the USB connectors. Doing so will damage the motherboard!
NOTE: The USB 2.0 module is purchased separately.
