Handleiding
Je bekijkt pagina 24 van 37
3-6 Chapter 3: OSD (On-Screen Display) menu
4. PIP/PBP
The PIP/PBP menu allows you to open up another sub-window connected
from another video source (when input source is below 60Hz) besides the
main-window from your original video source.
To activate this function, you need to do the following: turn off
MediaSync/
VRR/Dynamic Dimming
and disable HDR on your device.
Preset
Native Mode
Signal
DisplayPort
Brightness
50
ExitBack Enter
QuickFit Plus
Preset
Palette
PIP Size
PIP/PBP
Mode
Source
Color Setting
PA27JCV
5120 x 2880_60Hz
• Mode: Selects PIP, PBP function, or turn it off.
To scale both displays to full screen in PBP mode, set resolution
settings for both as 5120 x 2880 in OS display settings. (And make
sure that the scaling option is "Maintain Display Scaling" if you are
using an Intel graphic card.)
• Source: Selects the video input source from among HDMI,
DisplayPort and USB Type-C. The table below shows the input
source combinations.
• Color setting: Select color Preset for Main and Sub windows.
• PIP Size: Adjusts the PIP size to Small, Medium or Large (Only
available for the PIP mode).
