2-1ASUS PA27JCV Series LCD Monitor
2.1 Assembling the monitor arm/base
To assemble the monitor base:
1. Make sure the triangle marks of VESA cover aligned.
2. Attach the arm into the VESA cover.
3. Shut the lock to make the arm and VESA cover assembled.
4. Have the front of the monitor face down on a table, slide the tabs on the arm
into the slots on the VESA cover.
5. Press down the arm assembly to snap it into place.
6. Attach the base into the arm, making sure the tab on the arm fits into the
groove on the base.
7. Fix the base to the arm by fastening the bundled screw.
We recommend that you cover the table surface with soft cloth to prevent damage
to the monitor.
96W
1
2
3
7
4
5
6
Base screw size: M6 x 16.2 mm.
