42
Your Embedded Computer comes with an M.2 (B-key, supports
3042/3052) slot that allows you to install an M.2 5G/4G/UDR GPS module.
3.7 Installing an M.2 B-key module
To install an M.2 5G module:
1. If the standoff is already seated in the right mounting hole to t
your M.2 module, skip to step 3.
2. Unscrew the standoff and install it to a mounting hole that
matches the length of your M.2 module.
3. Align and insert the M.2 module into the slot, press it down, and
secure it in place using a screw.
4. Connect the antennas to your M.2 module.
ANT.4
ANT.1
ANT.5
ANT.6
WARNING! RF modules are intended for OEM or host integrators
only. For availability of system level RF certication, check with
your OEM integrator.
