22
2.1 Getting started
2.1.1 Connect a power supply to your Embedded
Computer
IMPORTANT! Ensure to use a power supply with a rated output power
of 480 W (purchased separately).
A. Insert the exposed wire end of the power terminal block to your power
supply’s terminal block as shown in the Power supply connection:
terminal block section. Tighten the screws or close the clamps on the
terminal block to secure the wires in place.
B. Insert the other end of the power terminal block to power jack adapter
to your Embedded Computer’s power (DC) input, then secure it with
the two screws on the terminal block connector.
C. Insert the exposed wire end of the AC power cord to your power
supply’s terminal block as shown in the Power supply connection:
terminal block section. Tighten the screws or close the clamps on the
terminal block to secure the wires in place.
D. Plug the power supply (purchased separately) into a 100 V ~ 240 V
power source.
