72
PE Series
To install an antenna:
NOTE: If your Embedded Computer came pre-installed with Wi-Fi
module antenna jacks, skip to step 9.
1. Remove the bottom cover. Refer to Removing the bottom cover for
details.
2. Prepare the RF connector and cable.
3. If the metal cover of the punch-out port is still intact or if there is a
rubber cap covering the antenna hole, remove it.
WARNING! Take extra care when removing the metal cover. Use tools
such as a screw driver to remove the metal cover to avoid physical
injury.
4. Insert the antenna jack end of the RF connector and cable into the
antenna hole from within the chassis outwards.
5. Insert the bundled O-ring over the antenna jack.
6. Secure the antenna jack using one of the bundled hex screws.
7. Connect the other end of the RF connector and cable to your Wi-Fi
module (refer to Installing a Wi-Fi module to the M.2 (E-key) slot for
details) or to your WWAN card (refer to Installing a cellular network
module to the M.2 (B-key) slot for details).
8. Replace the bottom cover. Refer to Replacing the bottom cover for
details.
9. Screw the external Wi-Fi antennas onto their corresponding antenna
jacks on the front and rear panels by turning them in a clockwise
direction.
10. Position the antennas for optimal signal reception.
