64
PE Series
3.7 InstallingaWi-Fimoduletothe
M.2(E-key)slot
WARNING! RF modules are intended for OEM or host integrators only.
For availability of system level RF certication, check with your OEM
integrator.
1. Remove the M.2 screw.
2. Align and insert the Wi-Fi module into the M.2 slot inside the
Embedded Computer.
3. Gently push down the Wi-Fi module on top of the standoff, and then
fasten it using the previously removed screw.
NOTE: We recommend using a PH1 screwdriver with a torque of
2.0±0.2kgf-cm when tightening the screw.
4. (Optional) Connect the RF cables from the antennas to your Wi-Fi
module. Make sure that the correct cable is attached to each of the
connectors by referring to the illustration on the next page.
NOTE:
• Please refer to the Installing antennas section for more
information on installing the antennas.
• Connecting antennas to your Wi-Fi module may strengthen the
wireless signal.
• A soft clicking sound indicates that the antenna has been securely
attached on the Wi-Fi module.
