20
Table 15. M.2 2230 Module (Mechanical Key E) Connector
#
Requirement
Details
1
Slot form
Factor
M.2 22x30 -
http://www.pcisig.com/members/downloads/PCIe_M.2_Electromechanical_Spec_Rev1.0_Final_11012013_RS_Clean.
pdf
2
Number of
Slots
1
3
Slot Type
Key “E” must meet Gold plating requirements in section 2.6.28.
4
Slot Nut, Post
1x solder nut installed @ 30mm position, pre-installed with 1x post w/wireless card installed in the 22x30 slot.
5
Power Delivery
Requirement
3.3V
DC
@ 2.75A
6
Slot Signals
Pin
Signal Name
Pin
Signal Name
74
3.3V
75
GND
72
3.3V
73
WT_CLKP
70
UIM_POWER_SRC/GPIO1/PEWAKE1#
71
WT_CLKN
68
CLKREQ1#
69
GND
66
PERST1#
67
WTD0P
64
REFCLK0
65
WTD0N
62
ALERT#/A4WP_IRQ# (I)(0/3.3)
63
GND
60
I2C CLK/A4WP_I2C_CLK (O)(0/3.3)
61
WT_D1P
58
I2C DATA/A4WP_I2C_DATA (I/O)(0/3.3)
59
WT_D1N
56
W_DISABLE1# (O)(0/3.3V)
57
GND
54
W_DISABLE2# (O)(0/3.3V)
55
PEWAKE0# (I/O)(0/3.3V)
52
PERST0# (O)(0/3.3V)
53
CLKREQ0# (I/O)(0/3.3V)
50
SUSCLK(32kHz) (O)(0/3.3V)
51
GND
48
COEX1 (I/O)(0/1.8V)
49
REFCLKN0
46
COEX2(I/O)(0/1.8V)
47
REFCLKP0
44
COEX3(I/O)(0/1.8V)
45
GND
42
CLink_CLK (I/O); NC for SR project
43
PERn0
40
CLink_DATA (I/O); NC for SR project
41
PERp0
38
C-Link RESET* (I) (0/3.3V); NC for SR
project
39
GND
36
UART RTS/BRI_DT (I) (0/1.8V)
37
PETn0
34
UART CTS (O) (0/1.8V)
35
PETp0
32
UART TXD/RGI_DT (I) (0/1.8V)
33
GND
30
Connector Key
31
Connector Key
28
Connector Key
29
Connector Key
26
Connector Key
27
Connector Key
24
Connector Key
25
Connector Key
22
UART RXD/BRI_RSP (O) (0/1.8V)
23
WGR_CLKP
20
UART WAKE# (O) (0/3.3V)
21
WGR_CLKN
18
GND/LNA_EN
19
GND
16
LED2#
17
WGR_D0P
14
PCM_OUT/I2SSD_OUT/CLKREQ0
15
WGR_D0N
12
PCM_IN/I2SSD_IN
13
GND
10
PCM_SYNC/I2SWS/RF_RESET_B
11
WGR_D1P
8
PCM_CLK/I2SSCK
9
WGR_D1N
6
LED1#
7
GND
4
3.3V
5
USB_D-
2
3.3V
3
USB_D+
1
GND
