17
2.6 Hardware Management Subsystem
2.6.1 Fanless Thermal Solution
The chassis is required to be fanless, thermally and environmentally robust in lower air-quality
environments (i.e., dust, 40°C ambience, etc.). Bravo will not be used outdoors.
Fan-less thermal solution meets these requirements:
• The chassis and thermal solution are designed so all system configurations do not
exceed 70C skin temp at 35C ambient.
• We can exceed 70C skin temperature at higher ambience. Some SKUs have been
tested at 40C and 50C for respective configurations as defined by the PRD
workloads.
• Warning labels and or notifications are provided to customers if skin temps
exceeding 80C under ambient conditions > 35C.
2.6.2 System States and Power States
Table 13 describes the ACPI states supported by the processor.
2.6.3 Wake-up Devices and Events
Lists devices or specific events that can wake the computer from specific states.
Bravo Canyon must support the wake-up events listed below. Note that S4 implies OS support only.
Table 12. LAN Wake Events
Wake-Up Event
State from Sleep
Power button
Modern Standby, S4, S5
RTC alarm
Modern Standby, S4, S5
LAN
Modern Standby, S5
USB
Modern Standby, S4, S5
PCIe
Modern Standby, S4
Bluetooth
Modern Standby, S4
Wi-Fi
Modern Standby, S4, S5
WWAN
Modern Standby, S4, S5
NOTE
The use of these wake-up events from an ACPI state requires an operating system that
provides full ACPI support. In addition, software, drivers, and peripherals must fully support
ACPI wake events.
