Product Overview
17
Communication
Intel® Wi-Fi 6E
1
AX211 (Gig+) M.2 1216 Soldered down module
• 802.11ax R2 2x2, both with 160Mhz channel support + Bluetooth v5.3
• Maximum transfer speed up to 2.4 Gbps
• Intel® AMT/vPro support on Core i5 vPro and Core i7 vPro SKUs only
More information about Intel® wireless products can be found at https://ark.intel.com
To obtain drivers visit https://www.asus.com/support/Download-Center/
Gigabit (10/100/1000/2500 Mbps) LAN subsystem using the Intel® i226-LM Gigabit
Ethernet Controller (vPro SKUs) and Intel® i226-V Gigabit Ethernet Controller (non-vPro
SKUs)
• PCIe 3.1 5GT/s support for p15-x1 width (Lane)
• Single-port integrated multi-gigabit (up to 2.5G) – standard IEEE 802.3 Ethernet
interface for 2500BASE-T, 1000BASE-T, 100BASE-TX, 10BASE-TE connections
(IEEE 802.3, 802.3u, 802.3bz, and 802.3ab)
• Full wake up support (S4 WOL not supported)
• Supports for packets up to 9.5 KB (Jumbo Frames)
More information about Intel® Ethernet controllers can be found at https://ark.intel.com
†
Thunderbolt™
2 x Thunderbolt™ ports (back panel)
• USB4 compliant
• 15W (5V/3A) port bus power
• Thunderbolt networking
• Protocol support:
PD Modes Supported: TBT3, USB4, USB3, DP-alt/MF
TBT3 Tx/Rx rates: 40G (2x 20.625), 20G (2x 10.3125)
PCI Express Tunneling: 32 Gbps (PCI Express* 3.0 p15-x4 compliant)
USB4 Tx/Rx rates: 40G (2x 20), 20G (2x 10)
USB3 Native: USB 3.2 Gen 2 p15-x1 (10G)
USB3 Tunneling: USB 3.2 Gen 2 p15-x1 (10G)
USB2: 480 Mpbs
DP1.4a, HBR3
DisplayPort Tunneling:
Port 1: 2 streams (~35 Gbps, Thunderbolt 4 certified)
Port 2: 2 stream (~35 Gbps, Thunderbolt 4 certified)
More information about the location of the Thunderbolt™ ports can be found in Section 2.1.4
later in this document
USB Ports and Headers
†
2 x USB 4 ports via Type C/Thunderbolt™ (on back panel, shared with Thunderbolt™ as
described above)
3 x USB 3.2 Gen 2 ports (2 front panel and 1 back panel)
1 x USB 2.0 port (1 back panel)
2 x USB 2.0 Headers (internal)
More information about the location of the USB ports and headers can be found in Section 2
later in this document
More information about the pinout of the USB ports and headers can be found in Section 4.1
later in this document
TPM
Intel® Platform Trust Technology (Intel® PTT) supported on all SKUs - TPM 2.0 Compliant
More information about TPM and Intel® PTT is available on https://www.asus.com/support/
Power
AC Adapter
• Core 3 ships with a 90W 19V adapter
• Core Ultra 5, Core Ultra 7 ships with a 120W 19V adapter
• Core Ultra 9 ships with a 150W 19.5V adapter
Internal Power Header
• 4-pos/dual row (2x2) right-angled header
Power Input
