10
NUC11TNKv5, NUC11TNKv7
User Guide – January 2021
4.0 Changing the M.2 SSD
The Intel® NUC 11 Pro Mini PC NUC11TNKv5 and Intel® NUC 11 Pro Mini PC
NUC11TNKv7 support an 80mm and 42mm SSD.
Pre-installed M.2
Intel® NUC 11 Pro Mini PC NUC11TNKv5
500GB Gen 4 NVMe SSD
Intel® NUC 11 Pro Mini PC NUC11TNKv7
500GB Gen 4 NVMe SSD
Find compatible M.2 SSDs in the Intel Product Compatibility Tool:
• Intel® NUC 11 Pro Mini PC NUC11TNKv5
• Intel® NUC 11 Pro Mini PC NUC11TNKv7
To install a different M.2 SSD:
1. Remove the small silver screw from the 80mm or 42mm metal standoff on the
board (A).
2. Remove the pre-installed SSD/Intel Optane Memory from the connector.
3. Align the space at the bottom of the new M.2 SSD to the key on the connector.
4. Insert the bottom edge of the M.2 SSD into the connector (B).
5. Secure the card to the standoff with the small silver screw (C).
