N97T-IM-A
2-2
17.0cm(6.7in)
17.0cm(6.7in)
CHASSIS
F_AUDIO
STEREO_OUT_L
ALC
897
STEREO_OUT_R
AUDIO
HDMI_DP2
DP1
Super
I/O
128Mb
BIOS
PCIEX1(G3)
M.2_(SOCKET3)
M.2(WIFI)
LVDS_EDP
LCD_BLKT_PANEL
GPIO_CON
KBMS_CON
USB_7
TPM
AT_ATX_SEL
VR_PROG
VCC_PWR_SEL
SPEAKER
F_PANEL
BATTERY
CLRTC
CHA_FAN
DC_PWR1
DC_PWR2
COM2_SEL
COM1_SEL
LAN12
DDR5 So-DIMM_A (64bit, 204-pin module)
SATA6G_2SATA6G_1
SATA_PWR1SATA_PWR2
COM_DEBUG
I2C
COM2
COM1
COM4
COM3
COM6
USB_56
COM5
PANEL_SW
Intel
®
Processor N97
RTL
8111H
RTL
8111H
USB_12
U5G_12
BKLTEN_SEL
22602280 2242
PCIE SATA IRST
X2 V X
11
5
8
9
6
7
17
18
19
15
14
16
21
20
22
2425 23
29
30
28
27
26
1 4 32
12
10
13
2.2 Motherboard layout
Place this side
towards the rear
of the chassis
NOTE: Place four screws into the holes indicated by circles to secure the
motherboard to the chassis.
CAUTION! Do not overtighten the screws! Doing so can damage the
motherboard.
NOTE: The audio codec may vary between motherboards, please consult
your sales window for the motherboards’ exact codec type.
