H610T-EM-A
1-2
1.3 Specications
(continued on the next page)
CPU
LGA1700 socket for Intel
®
14
th
/13
th
/12
th
Gen. Core™ i9/ i7/ i5/ i3,
Pentium
®
, and Celeron
®
Processors
Supports up to 65W
Chipset Intel
®
H610 Chipset
Memory
2 x SO-DIMM, max.64GB, DDR4 3200/2933/2666/2400 MHz
SDRAM
Graphics
Multi-output support: DisplayPort/eDP ports
- Supports DisplayPort output with a maximum resolution of
4096 x 2160 @ 60Hz
- Supports Embedded DisplayPort output with a maximum
resolution of 4096 x 2160 @ 60Hz (colay with LVDS,
optional)
Expansion slots
1 x M.2 Socket 3 with key M, type 2242/2260/2280 (SATA/PCIe
x4 mode)
1 x M.2 Socket 1 with Key E, type 2230 for WIFI/BT device (PCIe
& CNVi)
Storage
3 x SATA Gen 3.0, up to 6.0 Gb/s ports
1 x M.2 Socket 3 with key M, type 2242/2260/2280 (SATA/PCIe
x4 mode)
LAN
2 x LAN (RJ45) ports:
1 x Intel
®
i219V
1 x Realtek 8111H
Audio
Realtek ALC 897 High Denition Audio
Line-Out, Mic in
Rear I/O ports
3 x DisplayPort
4 x USB 3.2 Gen 1 ports
2 x LAN (RJ45) ports
2 x Audio jacks
1 x DC-in jack
Internal I/O
connectors
4 x COM Port headers (1 x RS232/422/485, 3 x RS232)
2 x USB 2.0 headers support 4 additional USB 2.0 ports
1 x CPU Fan header (PWM mode)
1 x Chassis Fan header (PWM mode)
1 x Chassis Intrusion header
1 x Front Panel Audio header (AAFP)
1 x System Panel header
1 x Clear CMOS header
1 x Stereo Speaker header
1 x COM Debug header
