Single Board Computer
41
3.3 Installing an M.2 SSD
1. (Optional) If a wireless card is installed, remove the screw holding it in
place (A), replace it with a standoff (B), and skip to step 3.
NOTE: We recommend using a PH1/sleeve screwdriver with a torque of
2.0±0.2kgf-cm when tightening the stando.
2. (Optional) Replace the stando if it was removed.
NOTE: We recommend using a PH1/sleeve screwdriver with a torque of
2.0±0.2kgf-cm when tightening the stando.
3. Align and insert the M.2 SSD into its slot inside the Single Board
Computer.
4. Gently push down the M.2 SSD on top of the stando, and then fasten
it using a screw.
NOTE: We recommend using a PH1 screwdriver with a torque of
2.0±0.2kgf-cm when tightening the screw.
