English
Redirection COM Port
Use this item to select a COM port to display redirection of Legacy OS and Legacy OPROM
Messages.
Resolution
On Legacy OS, the Number of Rows and Columns supported redirection.
Redirection Aer POST
If the [Bootloader] is selected, legacy console redirection is disabled before booting to
legacy OS. If [Always Enable] is selected, legacy console redirection is enabled for legacy
OS. e default value is [Always Enable].
Serial Port for Out-of-Band Management/Windows Emergency
Management Services (EMS)
Console Redirection EMS
Use this option to enable or disable Console Redirection. If this item is set to Enabled, you
can select a COM Port to be used for Console Redirection.
Console Redirection Settings
Use this option to congure Console Redirection Settings, and specify how your computer
and the host computer to which you are connected exchange information.
Out-of-Band Mgmt Port
Microsof t Windows Emergency Management Services (EMS) allows for remote
management of a Windows Server OS through a serial port.
Terminal Type EMS
Use this item to select the preferred terminal emulation type for out-of-band management.
It is recommended to select [VT-UTF8].
Option Description
VT100 ASCII character set
VT100+ Extended VT100 that supports color and function keys
VT-UTF8 UTF8 encoding is used to map Unicode chars onto 1 or more bytes
ANSI Extended ASCII character set
Bits Per Second EMS
Use this item to select the serial port transmission speed. The speed used in the host
computer and the client computer must be the same. Long or noisy lines may require lower
transmission speed. e options include [9600], [19200], [57600] and [115200].
Flow Control EMS
Use this item to set the flow control to prevent data loss from buffer overf low. When
sending data, if the receiving buers are full, a "stop" signal can be sent to stop the data
ow. Once the buers are empty, a "start" signal can be sent to restart the ow. Hardware
ow uses two wires to send start/stop signals. e options include [None], [Hardware RTS/
