2.4 Installation of Memory Modules (DIMM)
is motherboard provides eight 288-pin DDR4 (Double Data Rate 4) DIMM slots in two
groups, and supports Eight Channel Memory Technology.
CPU1
A1 B1 C1 D1 E1 F1 G1 H1
1 DIMM
#
2 DIMMS
# #
4 DIMMS
# # # #
8 DIMMS
# # # # # # # #
1. It is not allowed to install a DDR, DDR2 or DDR3 memory module into a DDR4 slot;
otherwise, this motherboard and DIMM may be damaged.
2. For eight channel conguration, you always need to install identical (the same brand,
speed, size and chip-type) DDR4 DIMM pairs.
DDR4 Socket Level Population Requirements
A1(CH0)
B1(CH1)
C1(CH0)
D1(CH1)
E1(CH0)
F1(CH1)
G1(CH0)
H1(CH1)
iMC0 iMC2
iMC1 iMC3
DDR4 Main Memory
Concept Diagram
