English
No. Description
1 Backplane PCI Express Hot-Plug Connector (CPU1_HSBP1)
2 PSU SMBus Header (PSU_SMB1)
3 System Fan Connector (FAN1)
4 ATX Power Connector (ATXPWR1)
5 ATX 12V Power Connector (ATX12V1)
6 USB 3.2 Gen1 Header (USB3_5_6)
7 ATX 12V Power Connector (ATX12V1)
8 System Fan Connector (FAN2)
9 LGA 4189 CPU Socket (CPU1)
10 CPU VSENSE Header (CPU_VSENSE)
11 PWM Conguration Header (PWM_CFG1)
12 System Fan Connector (FAN3)
13 System Fan Connector (FAN4)
14 SATA DOM Power Connector (SATAPWR2
15 SATA3 DOM Connector (SATA_5)
16 2 x 288-pin DDR4 DIMM Slots (DDR4_E1, DDR4_G1)*
17 SATA3 DOM Connector (SATA_4)
18 System Fan Connector (FAN5)
19 2 x 288-pin DDR4 DIMM Slots (DDR4_F1, DDR4_H1)*
20 M.2 Socket (M2_1) (Type 2242/2280/22110)
21 Mini-SAS HD Connector (SATA_0_3)
22 SATA3 Connectors (SSATA_3)(Upper), (SSATA3_2)(Lower)
23 SATA3 Connectors (SATA_7)(Upper), (SATA3_6)(Lower)
24 Speaker Header (SPEAKER1)
25 USB 2.0 Header (USB_2_3)
26 Virtual RAID On CPUHeader (RAID_1)
27 System Panel Header (PANEL1)
28 Auxiliary Panel Header (AUX_PANEL1)
29 M.2 Socket (M2_2) (Type 2242/2280/22110)
30 TPM-SPI Header (TPM_BIOS_PH1)
31 Security Override Jumper (SEC_OR1)
32 Vertical USB 2.0 Port (USB_1)
33 Front LAN LED Header (FRONT_LED_LAN34)
