SIENAD8-2L2T
2 3
English
Hardware Monitor
Temperature CPU, MB, LAN, Card side, TR1 Temperature sensing
Fan - Fan Tachometer
- Quiet Fan (Allow Chassis Fan Speed Auto-Adjust by CPU
Temperature)
- Fan Multi-Speed Control
Voltage VDDCR_CPU, VDDCR_SOC, VDDIO, VDD_18_S5,
VDD_33_S5, VDD_11_S3, +3V, +5V, +12V, +BAT, +1V8SB,
3VSB, 5VSB
Server Management
BMC Controller ASPEED AST2600
IPMI Dedicated
GLAN
1 Realtek RTL8211F for dedicated management GLAN
System BIOS
Type AMI UEFI BIOS; 256 Mb SPI Flash ROM
Features ASRock Rack Instant Flash, ACPI 6.4 and about compliance
wake up events, SMBIOS 3.5.0 and above, Plug and Play(PnP)
Internal Connectors/Headers
PSU Connectors 1 (4-pin, ATX PSU signal) w/ ATX 24-pin adapter cable, 2 (8-
pin, ATX 12V)
Auxiliary Panel
Header
1 (18-pin): chassis intrusion, system fault LED, LAN1/LAN2
activity LED, locate, SMBus
System Panel
Header
1 (9-pin): power switch, reset switch, system power LED,
HDD activity LED
NMI Header 1
Front Lan LED
Header
1
COM Header 1
Speaker Header 1 (4-pin)
Fan Headers 6 (6-pin)
ermal Sensor
Header
1
Buzzer 1
TPM Header 1 (13-pin, SPI)
HSBP 1
SMbus Header 1
PMbus Header 1
IPMB Header 1
Clear CMOS 1 (contact pads)
USB 3.2 (Gen1)
Header
1 header (19-pin, USB3.2 Gen1)
Others 1 header (9-pin, NCSI)
